Various machines and equipments are installed inside our company for swift testpiece making and mass production.

Cutting Machines

• 5-axis Control Machining Center

  Available for making test pieces from aluminum to titanium

  Model	N2-5XA
  Manufacturer	Makino Inc.
  Travel Distance (X x Y x Z)	300 x 300 x 230 ㎜
  Main Spindle Rotation Speed	200 ～ 20,000 min-1
  Positioning Accuracy	± 0.005 ㎜
  Repeated Positioning Accuracy	± 0.002 ㎜
  Function	3D free countouring



• CNC Automatic Lathe

  Model	SB-12R typeG
  Manufacturer	Star Micronics Co., Ltd.
  Maximum Machining Diameter	φ 13 ㎜
  Main Spindle Rotation Speed	MAX. 15,000 min-1
  Function	High accuracy cutting



• 3-axis Control Machining Center

  Model	ROBODRILL α-D14SiB5
  Manufacturer	Fanuc Corporation
  Travel Distance (X x Y x Z)	300 × 400 × 330 mm
  Main Spindle Rotation Speed	24,000 min-1
  Positioning Accuracy	± 0.006 ㎜
  Repeated Positioning Accuracy	± 0.004 ㎜
  Function	High accuracy cutting with high speed rotation of the spindle



Measuring Instruments

• Benchtop Scanning Electron Microscope / Energy Dispersive X-ray Spectrometer (EDS)

  Model	JCM-6000 / JED-2300
  Manufacturer	JEOL Ltd.
  Magnifying Power	× 10 ～ 60,000
  Function	Inspection of shape and surface condition under large magnification Simple dimension measurement Component analysis



• Micro Vickers Hardness Testers

  Model	HMV-G
  Manufacturer	Shimadzu Corporation
  Magnifying Power	98.07 mN ～ 19.807 N
  Function	Toughness measurements Toughness evaluation of brittle materials



• UV-VIS Spectrophotometer

  Model	UV-2600i
  Manufacturer	Shimadzu Corporation
  Measurement Wavelength Range	185 ～ 900 nm
  Resolution / Accuracy of Wavelength	0.1 ～ 5 nm
  System	Single monochromator
  Function	Thickness measurements of transparent liquid samples



• Optical Comparator

  Model	IM-8000 / 8020
  Manufacturer	Keyence Corporation
  Field of View	200 ㎜ × 200 ㎜ (Wide-Field Measurement Mode) 125 ㎜ × 125 ㎜ (High-Precision Measurement Mode)
  Minimum Unit	0.1 µm
  Repeatability (Without Stage Movement, With Stage Movement)	± 1 µm, ± 2 µm (Wide-Field Measurement Mode) ± 0.5 µm, ± 1.5 µm (High-Precision Measurement Mode)
  Measurement Accuracy ±2σ (Without Binding, With Binding)	± 3.9 µm, ± (7+0.02L) µm (Wide-Field Measurement Mode) ± 2 µm, ± (4+0.02) µm (High-Precision Measurement Mode)
  Function	Measurement of 300 locations in 3 seconds



• Optical Comparator

  Model	LM-1000 / 1100
  Manufacturer	Keyence Corporation
  Field of View	225 ㎜ × 125 ㎜ (Wide-Field Measurement Mode) 206 ㎜ × 106 ㎜ (High-Precision Measurement Mode)
  Minimum Unit	0.1 µm
  Repeatability (Inside Camera's Field of View, 2σ)	± 0.5 µm (Wide-Field Measurement Mode) ± 0.1 µm (High-Precision Measurement Mode)
  Measurement Accuracy (Inside Camera's Field of View, 2σ)	± 2 µm (Wide-Field Measurement Mode) ± 0.7 µm (High-Precision Measurement Mode)
  Function	High precision measurement



• Digital Microscope

  Model	VHX-8000
  Manufacturer	Keyence Corporation
  Magnifying Power	× 20 ～ 2,000
  Scanning Speed	× 20 of optical miroscope
  Function	3D depth composition, material identification



• FTIR Spectrometer

  Model	IRTracer-100
  S/N Ratio	60,000 : 1
  Wavenumber Range	7,800～350 cm-1
  Resolution	0.25cm-1
  Scanning Speed	20 spectra/second
  Function	Quantitative and qualitative analysis of a sample



Other Machines

• Injection Molding Machine

  A small-sized machine suitable for manufacturing testpieces using regins

  Model	C, Mobile0813
  Manufacturer	Shinko Sellbic Co., Ltd.
  Clamping Force	29 kN (3 tf)
  Function	Produce micro injection molding parts



• Wire EDM

  Specialized in micromachining and ultra-precision machining

  Model	UPN-01
  Manufacturer	Makino Inc.
  Travel Distance (X x Y x Z)	160 × 160 × 50 mm
  Function	Sub-micron level accuracy machining



• EDM Hole Drilling Machine

  Hole drilling suitable for micromachining and ultra-precision machining wire EDM

  Model	EDFH1
  Manufacturer	Makino Inc.
  Travel Distance (X x Y x Z)	220 × 180 × 300 mm
  Function	High accuracy EDM drilling



• Vacuum Impregnation Equipment

  Model	AW-2004040
  Manufacturer	Sato Vac Inc.
  Ultimate pressure	10 Pa and under (at no-load)
  Operation system	Degassing
  Impregnation	Automatic
  Function	Soak liquid to sample by the pressure difference between vacuum and atmospheric pressure



• 3D Printer

  Model	Objet30 Prime
  Manufacturer	Stratasys Ltd.
  Construction Method	Polyjet
  Layer Thickness	Z-axis : 14 μm, 28 μm, 36 μm
  Travel Distance (X x Y x Z)	294 x 192.6 x 148.6 mm
  Function	Construct three dimensional sample by piling layer based on 3D data



• 3D Scanner

  Model	Geomagic Capture
  Manufacturer	3D Systems Corporation
  Scanning Distance	300 ～ 480 mm
  Scanning Depth	180 mm
  Scanning Area (short distance)	124 x 120 mm
  Scanning Area (long distance)	190 x 175 mm
  Accuracy	0.06 mm
  Function	Capture the shape of three-dimensional object



• Laser Cutting and Engraving Machine

  Model	PLS6.75
  Manufacturer	Universal Laser Systems,Inc
  Travel Distance (X x Y x Z)	813 × 457 × 216 mm
  Wavelength of Laser	10.6 μm
  Diameter of Laser	127 μm
  Function	Laser cutting and engraving on resins
